CBB65-2 Features
1. Round-shape metal case, Three groups of lug terminals,and combining the capacitor of air-conditioner compressor with the capacitor of fan. (C for public pole, HERM for compressor pole, FAN for the fan pole)
2. With inner anti-explosion device, safe and reliable.
3. Low dissipation factor, high insulation resistance, good self-healing,stable performance,good ability of resisting impact current and overload
4. Suitable for air conditioner,refrigerator, washing machine, lighting,etc and beneficial to the starting and running of AC motor.
CBB65-2 Technial Data
- Ambient Temperature
- Rated Voltage
- Capacitance Range
- Test Voltage
- Capacitance Tolerance
- Dissipation Factor
- Operating Frequency
- Executing Standard
- -40 - +85℃
- 370 - 450VAC
- 1+1 - 80+15μF
- T-T:1.75Un/2s T-C:2200VAC/2s
- ±5%,±10%
- tg≤0.002(100Hz,20℃)
- 50/60HZ
- IEC60652,UL810,EN60252,VDE0560-8,GB/T3667.1-2005
CBB65-2 Outline Dimensions
| Capacitance Range | 370 - 400VAC | 400 - 450VAC | |||
| D(mm) | H(mm) | D(mm) | H(mm) | ||
| 1+1 - 80+15μF | 30 - 60 | 50 - 140 | 30 - 60 | 50 - 150 | |
